RJ45 CAT6 INLINE COUPLER KEYSTONE TYPE JE
AED 18.00
AED 25.00
| Parameter | Specification |
|---|---|
| Category Standard | ISO/IEC 11801, ANSI/TIA-568-C.2 (Cat.6A) |
| Structure Type | S/FTP (Each pair foil-shielded + Overall braid shield) |
| Conductor Material | Solid Bare Copper |
| Conductor Size | 26AWG |
| Insulation Material | HDPE (High-Density Polyethylene) |
| Jacket Material | PVC |
| Shielding | Aluminum Foil for each pair + Braided Overall Shield |
| Pair Count | 4 twisted pairs |
| Connector Type | RJ45 Modular Plug (8P8C), Gold-plated contacts |
| Plug Material | Transparent Polycarbonate |
| Boot Type | Molded Strain Relief / Snagless Boot |
| Color Options | Grey, Blue, Yellow, Green, Black, Red |
| Transmission Speed | 10 Gbps |
| Frequency Range | Up to 500 MHz |
| Testing Standard | Fluke Channel Test – PASS Cat.6A |
| Operating Temperature | -20°C to +75°C |
| Storage Temperature | -20°C to +75°C |
| RoHS Compliance | Yes |
- Datasheet. CAT 6A SFTP Patch cord_ACAHEXX060XXXXX(SA2)
