RJ45 CAT6 INLINE COUPLER KEYSTONE TYPE JE
AED 18.00
AED 25.00
Parameter | Specification |
|---|---|
Category Standard | ISO/IEC 11801, ANSI/TIA-568-C.2 (Cat.6A) |
Structure Type | S/FTP (Each pair foil-shielded + Overall braid shield) |
Conductor Material | Solid Bare Copper |
Conductor Size | 26AWG |
Insulation Material | HDPE (High-Density Polyethylene) |
Jacket Material | PVC |
Shielding | Aluminum Foil for each pair + Braided Overall Shield |
Pair Count | 4 twisted pairs |
Connector Type | RJ45 Modular Plug (8P8C), Gold-plated contacts |
Plug Material | Transparent Polycarbonate |
Boot Type | Molded Strain Relief / Snagless Boot |
Color Options | Grey, Blue, Yellow, Green, Black, Red, Orange |
Transmission Speed | 10 Gbps |
Frequency Range | Up to 500 MHz |
Testing Standard | Fluke Channel Test – PASS Cat.6A |
Operating Temperature | -20°C to +75°C |
Storage Temperature | -20°C to +75°C |
RoHS Compliance | Yes |
- Datasheet. CAT 6A SFTP Patch cord_ACAHEXX060XXXXX(SA2)
