RJ45 CAT6 INLINE COUPLER KEYSTONE TYPE JE
AED 18.00
AED 25.00
⚙️ Technical Specifications
| Item | Specification |
|---|---|
| Socket Type | BS1363 (UK-type 45° angled outlet) |
| Socket Quantity | 10 Way |
| Power Input | IEC320 C20 Plug (16A) |
| Bracket Install | Left-end single input |
| Installation Type | Inverse installation (Vertical) |
| Cable Specification | 3 × 1.5 mm² × 3 m |
| Rated Voltage | 250 V AC, 50/60 Hz |
| Rated Current | 16 A |
| Max. Current | 16 A |
| Max. Power | 4000 W |
| PDU Exponent | 1.467 |
| Control Function | None |
| Protection Function | None |
| Connection Wire | Internal 1.5 mm² (16 AWG) |
| Cable Clamp | Type (11) – Fixed clamp |
| Case Color | Black |
| Material | Metal Body |
| Dimensions (L × W × H) | 723 × 44.4 × 62 mm |
| Mounting Length | 697 mm |
| Case Length | 667 mm |
| Case Tolerance | ±1.0 mm |
| Fittings | 2 pcs φ6×16 mm cross bolts, 2 pcs M6 floating nuts |
| Safety Certification | CE |
| Environmental Compliance | RoHS |
| Manufacturer | SHENZHEN CLEVER ELECTRONIC CO., LTD |
| Brand | AMT |
