RJ45 CAT6 INLINE COUPLER KEYSTONE TYPE JE
AED 18.00
AED 25.00
⚙️ Technical Specifications
| Item | Specification |
|---|---|
| Socket Type | 12 × IEC320 C13 (Single) + 4 × IEC320 C19 (Single) |
| Socket Quantity | 16 Way |
| Power Input | IEC60309 Industrial Plug (32A, 2P+E, Blue) |
| Bracket Install | Left-end single input |
| Installation Type | Inverse installation |
| Cable Specification | 3 × 6.0 mm² × 3 m |
| Rated Voltage | 250 V AC, 50/60 Hz |
| Rated Current | 32 A |
| Max. Current | 32 A |
| Max. Power | 8000 W |
| PDU Exponent | 1.371 |
| Control Function | 32A Master Air Circuit Breaker |
| Protection Function | None |
| Connection Wire | Internal wire 2.5 mm² (14 AWG) |
| Cable Clamp | Type (19) – Fixed cable clamp |
| Case Color | Black |
| Material | Metal |
| Dimensions (L × W × H) | 932 × 44.4 × 62 mm |
| Mounting Length | 904 mm |
| Case Length | 876 mm |
| Case Tolerance | ±1.0 mm |
| Fittings | 2 pcs φ6×16 mm cross bolts, 2 pcs M6 floating nuts |
| Safety Certification | CE |
| Environmental Compliance | RoHS |
| Manufacturer | SHENZHEN CLEVER ELECTRONIC CO., LTD |
| Brand / Label | AMT |
