RJ45 CAT6 INLINE COUPLER KEYSTONE TYPE JE
AED 18.00
AED 25.00
Specifications
| Parameter | Details |
|---|---|
| Fiber Type | Singlemode (SM) |
| Core / Cladding Diameter | 9 / 125 µm |
| Connector Type | LC to SC |
| Polish Type | UPC |
| Jacket Material | LSZH (Low Smoke Zero Halogen) |
| Jacket Diameter | 2.0 mm |
| Cable Length | 5 meters |
| Color | Yellow |
| Insertion Loss (Typical) | ≤ 0.3 dB |
| Return Loss | ≥ 50 dB |
| Operating Wavelengths | 1310 nm / 1550 nm |
| Operating Temperature | -20°C ~ +70°C |
| Storage Temperature | -40°C ~ +85°C |
| Compliance | RoHS, IEC 61754, TIA/EIA 568-C.3 |
Key Features
- High-precision LC and SC connectors for stable signal transmission
- LSZH jacket for safety in enclosed spaces
- Factory-tested for insertion and return loss
- Ideal for data centers, telecom, and enterprise networks
- Durable construction with excellent mechanical strength
