Name: Kuwes SC Simplex 50/125µm OM4 Pigtail, 1 Meter, LSZH
Brand: Kuwes
SKU: SF-2443-4O5Z
Price: 25 AED
Availability: InStock

Email to a Friend

Kuwes SC Simplex 50/125µm OM4 Pigtail, 1 Meter, LSZH

Brands: Kuwes

AED 25.00 AED 35.00 -28% Off

📋 Product Overview

Detail	Specification
Product Name	Kuwes SC Simplex 50/125µm OM3 Multimode Fiber Pigtail
Part No.	12-OFMFMK#1M
Fiber Type	OM4 Multimode
End Configuration	Pigtail: SC Connector on one end, Bare Fiber on the other
Cable Length	1 Meter (1M)
Jacket Material	LSZH (Low Smoke Zero Halogen)
Color	Light Pink (Standard OM4 Color)

Detail	Specification	Notes
Product Name	Kuwes SC Simplex 50/125µm OM4 Multimode Fiber Pigtail
Part No.	12-OFMFMK#1M	Manufacturer's unique identifier.
Fiber Type	OM4 Multimode	High-performance, Laser Optimized Multimode Fiber (LOMMF).
Core/Cladding	50/125um	Standard size for OM3 and OM4.
Connector Type	SC Simplex	Single fiber connection with a push-pull mechanism.
End Configuration	Pigtail: SC Connector (End A), Bare Fiber (End B)	Designed for fusion or mechanical splicing.
Cable Length	1 Meter (1M)	Standard pigtail length.
Jacket Material	LSZH	Low Smoke Zero Halogen—essential for safety in public/indoor spaces.
Color	Light Pink	Standard color coding for OM4 fiber.

Parameter	Value (As per label/Industry Standard)	Significance
Insertion Loss (IL)	$0.17 db$	Extremely low factory loss, ensuring maximum signal quality after splicing.
Modal Bandwidth (EMB)	$4700 MHz. KM$	The high bandwidth rating of OM4 is its key performance differentiator.
10 Gigabit Ethernet (10GB) Range	Up to 550M	Significantly extends the range over OM3 (300M).
40/100 Gigabit Ethernet (40/100GbE) Range	Up to 150M	Supports high-speed parallel optics links (eg 40GBASE-SR4).
Compliance	RoHS Compliant	Safe and environmentally friendly manufacturing.
