RJ45 CAT6 INLINE COUPLER KEYSTONE TYPE JE
AED 18.00
AED 25.00
Technical Specifications:
| Parameter | Details |
|---|---|
| Brand | KUWES |
| Model / Part No. | 13-JJS324#1M |
| Cable Type | Duplex Singlemode Fiber (SM) |
| Fiber Size | 9/125 µm |
| Connector Type | SC/APC to SC/APC |
| Length | 1 Meter |
| Cable Jacket | LSZH (Low Smoke Zero Halogen) |
| Jacket Diameter | 2.0 mm |
| Color | Yellow |
| Insertion Loss (Typical) | ≤ 0.30 dB |
| Return Loss | ≥ 60 dB |
| Operating Wavelength | 1310 nm / 1550 nm |
| Polish Type | APC (Angled Physical Contact) |
| Cable Type | Duplex |
| Operating Temperature | -20°C to +70°C |
| Compliance | RoHS Compliant |
| Country of Origin | Made in Taiwan |
Key Features:
- High precision SC/APC connectors for low insertion loss
- Duplex configuration for bidirectional transmission
- LSZH jacket minimizes toxic smoke during fire exposure
- Factory tested and Q.C. PASS certified
- Suitable for telecom, LAN, WAN, and CATV systems
